OMIO CNC (X8-2200L-USB 110V)
Delivered from factory in 4-5 weeks
The OMIO X8-2200L-USB is a desktop CNC router for competition-robot fabrication — milling, drilling, contouring, and routing aluminum plate, Delrin / acetal, polycarbonate, SWYFT Composite, hardwood, and plywood / MDF. Every machine and edition on this page is a 110 V build. It is controlled over USB from a Windows PC running Mach3, and it uses a water-cooled 2.2 kW (2200 W) spindle. Machines ship directly from the factory in 4–5 weeks.
This is the shop staple widely used on FTC and FRC teams. We welcome purchase orders and tax-exempt purchasing for schools and registered teams.
Materials & applications
This router handles the stock competition robots are built from:
- Aluminum plate, including 6061 and 7075
- Delrin / acetal
- Polycarbonate
- SWYFT Composite (SRPP)
- Hardwood
- Plywood / MDF
Typical uses include structural brackets, drivetrain parts, and custom fixtures, so teams can mill parts in-house instead of sending them out. Starting speeds and feeds for these materials are in the owner's manual. Aluminum needs chip clearing with air or mist. Use a dust shoe and vacuum for wood and plastic.
Machine features
- Frame and bed — 6061-T5 extruded aluminum, with a T-slot aluminum bed for clamps and fixture plates.
- Motion — Ball screws (X/Z 1605, Y 2005) on HG20 linear rails. Positioning accuracy is 0.05 mm. Maximum feed rate is 4,000 mm/min.
- Spindle — 2.2 kW (2200 W) water-cooled spindle, 6,000–24,000 rpm, with an ER20 collet. A 6 mm collet is fitted and a 3.175 mm (1/8″) collet is included. With the appropriate ER20 collets, the spindle takes 1/8″ to 1/2″ end mills. The spindle must run on a closed water-cooling loop; running it without coolant will damage the bearings.
- Work area — 770 × 565 mm of travel, with 85 mm of Z travel (140 mm with the dust cover removed).
- Controller — The controller box carries the emergency stop, the spindle VFD, and the USB link to the PC. Limit switches are included. A wireless pendant is included on some builds.
- Layout — The spindle rides the gantry (X axis) and the gantry rides the bed (Y). Drag chains carry the spindle coolant lines and motor wiring.
Controller & software
The machine is controlled from Mach3 on Windows over USB. Install Mach3 and the USB motion-controller driver, then load the supplied XML profile for this machine. That profile contains the axis directions, steps-per-unit, soft limits, and spindle configuration — do not enter these values manually. Use the package that matches the machine's ship date: configuration changed in August 2024, and loading the wrong package produces axes that move the wrong distance or direction.
Program toolpaths in Fusion 360 or another CAM package and post with a Mach3-compatible post-processor. The machine accepts G-code.
Specifications
| Specification | X8-2200L-USB |
|---|---|
| Work area | 770 × 565 mm; Z 85 mm (140 mm with the dust cover removed) |
| Spindle | 2.2 kW (2200 W) water-cooled |
| Spindle speed | 6,000–24,000 rpm |
| Tool holding | ER20 collet — 6 mm fitted, 3.175 mm (1/8″) included. Takes 1/8″ to 1/2″ end mills with the matching collets. |
| Motion | Ball screws (X/Z 1605, Y 2005) on HG20 linear rails |
| Frame | 6061-T5 extruded aluminum |
| Bed | T-slot aluminum |
| Max feed | 4,000 mm/min |
| Positioning accuracy | 0.05 mm |
| Control | Mach3 on Windows, USB |
| CAM | Fusion 360 or any CAM that posts Mach3-compatible G-code |
| Power | 110 V (every machine and edition on this page) |
| Weight | 90 kg |
| Included | Limit switches. A wireless pendant is included on some builds. |
Closed-Loop Stepper Edition
A Closed-Loop Stepper edition of this same 110 V X8-2200L-USB is available for an additional $250. It uses closed-loop stepper motors in place of the standard steppers. Choose OMIO CNC (X8-2200L-USB 110V) Closed-Loop Stepper in the options above when you order. Power remains 110 V.
Documentation
The owner's manual covers safety, installation, Mach3 setup, tooling and workholding, speeds and feeds, operation, maintenance, and troubleshooting: Owner's manual.
Machines after August 2024:
Software, manual & Mach3 config
After you download the zip file, unzip it, then open Mach3-ConfigurationV3.pdf first and follow the instructions step by step.
Machines before August 2024:
Software, manual & setting files for X8-2200L-USB
After you download the zip file, unzip it, then open Mach3-ConfigurationV3.pdf first and follow the instructions step by step.
Wireless control handle instructions — use these only if the machine was supplied with the wireless pendant.
Shipping
CNC machines ship directly from the factory in 4–5 weeks. They ship freight with liftgate delivery. Shipping options are shown at checkout, and we coordinate delivery scheduling and provide pre-installation guidance before the machine arrives.
ER20 collet 10-pack
An optional ER20 Precision Spring Collet 10 Pack is available on this page for $109.99 (SKU CNC-0003).

Rout the parts you'd otherwise send out
Mill aluminum plate, Delrin, and polycarbonate to tight tolerances (structural brackets, drivetrain parts, and custom fixtures) without outsourcing or long lead times.

Rigid, repeatable, precise
A water-cooled spindle on a solid frame holds accuracy through real cutting loads, so parts come out to spec run after run.

Set up for schools and teams
Ships directly from the factory, runs on Mach3, and we welcome purchase orders and tax-exempt purchasing for schools and registered teams.

Closed-loop stepper edition
A closed-loop stepper edition of this same 110 V X8-2200L-USB uses closed-loop stepper motors in place of the standard steppers. It is listed at an additional $250, and power stays 110 V. Motor and drive details are coming soon.
- Spindle power
- 2200W
- Control
- USB
- Input
- 110V
Work envelope
770 × 565 mm of travel
Z travel is 85 mm, or 140 mm with the dust cover removed.
Material capability
Route what your robot is made of
A router earns its keep on the parts you'd otherwise send out. This one handles the stock competition robots are built from:
- Aluminum plate
- Delrin / acetal
- Polycarbonate
- SWYFT Composite
- Hardwood
Controller
Mach3 on Windows, over USB
The controller box carries the emergency stop, the spindle VFD, and the USB link to the PC. Limit switches are included. A wireless pendant is included on some builds.
- Install Mach3 and the USB motion-controller driver, then load the supplied XML profile. Do not enter axis directions, steps-per-unit, soft limits, or the spindle configuration manually.
- Use the package that matches the machine's ship date. Configuration changed in August 2024, and the wrong package moves axes the wrong distance or direction.
- Program toolpaths in Fusion 360 or another CAM package and post with a Mach3-compatible post-processor. The machine accepts G-code.
Compare the range
Find the right cnc machine for your team
The OMIO X8 is a staple in the robotics community. The 8060Z is a lower-cost alternative with similar performance, two work-area sizes, and more spindle and 4th-axis options.
You're viewingOMIO CNC (X8-2200L-USB 110V) | 8060Z CNC Machine | |
|---|---|---|
| Work area | 770 × 565 mm, Z 85 mm (140 mm with dust cover removed) | Two sizes: 575 × 375 mm or 790 × 580 mm |
| Spindle | 2200 W | 1500 W or 2200 W water-cooled |
| Collet | ER20 — 1/8″ to 1/2″ end mills | ER16 (1500 W) or ER20 (2200 W), 1/8″ included |
| Best for | The shop staple — widely used on FTC and FRC teams | Lower-cost alternative with similar performance, and more options |
| Starting price | From $3,999.99 | From $2,399.99 |
| This machine | View → |
